childrens bike kids,kids bike,kids bike child,kids bike children,kids bike for boy,kids dirt bike bicycle

kids moto bikes/kids motorcycle bike/baby boy kids bicycle with wattle bottle

Short Description:

Color: blue,red,green,orange
Available Size: 12',16'',20''
MOQ: 100 PCS

CONTACT NOW down load to pdf

Details

Tags

Wheel Size: 16″

Frame Material: Steel

Fork Material: Steel

Rim Material: Steel

Training Wheels: Yes

Net Weight: 12KG

Place of Origin: Hebei, China

Gross Weight: 13kg

Color: blue,red,green,orange

Available Size: 12′,16”,20”

Selling Units: Single item

Single package size: 108X18X60 cm

Single gross weight: 13.000 kg

Package Type: 1pc/carton,or custom package

kids moto bikes/kids motorcycle bike/baby boy kids bicycle

1.Steel Frame
2.Motor design
3.competitive price
4.with training wheels

Product Description

> tricycle stroller for kids

> two seat tricycle kids

#	Parts	Description	Part #	Color
1	FRAME	16″X13″ STEEL NON-SUSPENSION PULSE-WELDED,W/EN14765 STD	C21SZ18SJ	1.TC-6413 GREEN 2.YS-7416 ORANGE 3.YS-7490 BLUE
2	SHOCK	NIL
3	FORK	16″ #800 TYPE ,STEEL 31.8D BLADE, PULSE-WELDED,W/EN14765 STD	XC21CS18	1 & 2. YS-728 BK 3.YS-701 WH
4	FORK DUST COVER		N/L
5	FORK CAP	NIL
6	HANDLE BAR	STEEL, 520WX1.4TX60RX6DG, W/O CROSS BAR, W/EN14765 STD	HB-MC52002	ED BLACK
7	STEM	Y-TYPE, STEEL POST:22.2X1.6TX150L, W/MINI. INSERTION MARK,W/ EN14765 STD	HS-A01A1	ED BLACK
8	HEAD PARTS	STEEL, 8 PCS, KEY WASHER:3T, 22.2x30x27mm	XR-H1/H2	BLACK
9	GRIPS	TPR R/L 100MM	KW-K29	BLACK
10	F/BRAKE	CALIPER-BRAKE, STEEL 3.5T 2PCS AW SHOE	1000S	BLACK
11	R/FRAKE	NIL
12	BRAKE LEVER	ONLY LEFT OR RIGHT, STEEL BODY PP LEVER W/ADJ.	B212P	BLACK
13	BRAKE CABLES	ONLT FRONT	2P	BLACK
14	FRONT HUB	STEEL, 14Gx28Hx3/8″x85Wx120L, 3/8″AXLE, W/NUT	WR-801F2(HF-11)	ED/BK
15	REAR COASTER	STEEL, 14Gx28HX111Wx164L, 5/16″ AXLE, W/16T SPROCKET W/NUT	CF-E08	ED/BK
16	SPOKE	STEEL, 14GX28H W/12MM STEEL CP NIPPLE		UCP/CP
17	RIM	F/R 16″ STEEL 14GX28H, 1.05T	HB-2(7x)	ED-BK
18	TIRE	F/R 16″X1.95″	J-1001	BLACK
19	TUBE	F/R 16″x1.95″, A/V		BLACK
20	RIM STRIP	F/R 16X20MM		BLACK
21	CHAIN WHEEL	STEEL SOLID TYPE, 1/2×1/8″X28T	YL-502	ED-BLACK
22	CRANK	STEEL, 4-1/2″ W/O PIN, COLD-FORGE	YL-603	ED BLACK
23	CHAIN COVER	FOR 16″, PLASTIC FULLY TYPE 3 PCS	SM-C16	BLACK
24	B.B. PARTS	STEEL, 10-PCS MEDIUM BB SHELL	YL-702	UCP
25	CHAIN	STEEL, 1/2×1/8X68L	C410	GY/PS
26	PEDAL	PP BODY, 1/2″AXLE, W/BS REF & WARNING STICKER (R&L) W/BALL BEARING	PJ-462	BLACK
27	FREEWHEEL	NIL
28	T/WHEEL	PLASTIC, 5″	ZS-1004	BK/BK
29	T/WHEEL BRACKET	STEEL, 90DG REINFORCE, W/EN14765 STD	TWK-C01	1 & 2. YS-728 BK 3.YS-701 WH
30	T/WHEEL BOLT	STEEL, M8X37L		UCP
31	KICKSTAND	NIL
32	WING	R/L PP	MOP16-01/02	BK
33	F/FENDER	PP	MOP16-03	BK
34	TANK	PP	MOP16-04	BK
36	SADDLE BASE	PP	MOP16-05	BLACK
38	SADDLE LOWER BASE	PP	MOP16-06	BK
39	NUMBER PLATE	PP	MOP16-07	BK
35	SADDLE	#4 NON-SLIP TOP W/O LOGO		BLACK
37	SADDLE
40	MOULD AMORIZATION
41	TANK BRACKET	STEEL	MOS16-01A/01B	ED-BK
42	SADDLE BRACKET	NIL
43	NUMBER PLATE BRACKET	STEEL	MOS1620-03A	ED-BK
44	REFLECTOR	4PCS ECE STANDERED SL-121C/R SL-722A		WH/RED/YELLOW
45	REF BRACKET	XPJ3-53/MO-BK01		BK
46	PAD	PVC,1PCS FOR STEM		COLOR
